Sending A Radiogram Via WinLink

Bill1 Comment

WinLink is a powerful software tool for sending and receiving digital messages via amateur radio. This post shows how a National Traffic System radiogram is sent. Belowis the main WinLink software user interface. The “Message” tab at the top of the main page is selected and the “New Message…” command is selected to create a message.

The “Enter a new message” window appears. The message needs to be entered, addressed, and formatted to send a radiogram. To proceed, select the “Radiogram” tab. I have previously setup the tab since I frequently use that template. Otherwise, use the “Select Template” tab to find the Radiogram.txt template from the many other message templates.

In either case, the Radiogram template is brought up in your default web browser. The message number, call sign, date, and other defaults are already filled. The information for the addressee, message, signature, and liaison station is now entered.

Here the radiogram is ready for submission. The ARL designation in the body of the message is for one of the pre formatted numbered messages. In this case it’s for the “Greetings by amateur radio” message. The ‘X’ is a period and ‘73’ means “Best Regards.”

After the “Submit” button is clicked, the “Enter a new message” WinLink window now has the “To”, “Cc”, “Subject”, and formatted NTS radiogram message boxes filled.

When the radiogram is satisfactorily formatted, click on the “Post to Outbox” tab. The radiogram is now in the “Outbox” system folder in the main WinLink window. To send the message, verify that “Vara HF Winlink” is selected from the “Open Session” dropdown menu. Then click on the “Open Session” tab.

The “Vara HF Winlink Session”, and “Vara HF” modem windows are opened. Therese is the interface for the HF radio that is connected to the PC via a USB cable.

Click on the “Auto-connect” tab to set the frequency and begin transmitting. The software will cycle through the list of server stations until a connection is made. Then the message is sent, and any outstanding incoming messages are received.

Here is a video of the radio connection process.

Radiogram Transmission using VARA HF in WinLink

Field Day 2022

Bill1 Comment

Field Day has come and gone and I feel like I have had my best Field Day ever.

I made 80 unverified FT8 digital contacts with stations around The United States and Canada. Each of those contacts counts for 2 points for a total of 160 points. A 2x power multiplier makes that 320 points. I sent 59 and received 48 NTS formatted messages. Ten of those messages originated at my station and counted 10 points each. I also sent one to The Western Pennsylvania Section Manager which counted for 100 points during The Western Pennsylvania Phone Traffic Net. There are also 100 bonus points for submitting this post.

I have submitted my entry with a possible score of 670 points, which will be added to the results for my local radio club, The Nittany Amateur Radio Club.

Digital Traffic Network

Bill2 Comments

This week, my amateur radio station became an official digital traffic network (DTN) station. The main operating digital mode is PACTOR, an evolution of both AMTOR and packet radio. PACTOR uses a combination of simple phase shift keying (FSK) modulation, and the ARQ protocol for robust error detection and data throughput. PACTOR is most commonly used on frequencies between 1 MHz and 30 MHz.

I first looked into PACTOR last fall. I abandoned the idea when I learned that the terminal node controllers (TNCs) cost hundreds of dollars, an investment I was not comfortable making at the time. In December, I asked around about becoming a DTN station operator. I was told that the operational mode was PACTOR and I balked about having to obtain the necessary TNC. Then I was told that a used TNC would be provided. All I had to pay was a $15 dollar shipping charge. That was more than acceptable. Soon, the loaner TNC arrived. It was about 25 years old and supposedly could handle the required PACTOR digital node.

Advanced Electronic Applications, Inc. PK-232MBX TNC

I found a appropriate AC/DC adapter, but I had to jury-rig a mic cable to connect it to my radio and the 5 pins on the back of the TNC. I also had a audio cable on hand for the radio output to the TNC. An RS-232/serial port USB adapter cable connects the TNC to my laptop PC.

Breadboard for connecting a CAT6 twisted-pair cable to the TNC

The AirMail software was downloaded and installed on my laptop. That needed to be configured to interface with the TNC. The TNC was switched on and AirMail was opened. Following initialization of the HF mode, the TNC successfully initialized. My radio AGC was set to 6 and for 40 watts output. It was then tuned to a frequency for a nearby PACTOR station. Then the receive threshold was properly set on the TNC. I tried to connect to a PACTOR station but no joy.

After several days of troubleshooting, with the assistance of two fellow amateur radio operators, I tried a loopback test on the TNC. This involved disconnecting the TNC from the radio and connecting the mic and audio input pins, on the TNC, with a jumper wire. Then a terminal software app was setup to connect the TNC with itself. This test failed and indicated the problem was with the TNC.

I was able to obtain an identical TNC on eBay for a modest and very affordable price. When it arrived, I quickly set it up for a loopback test. The test was successful. I then connected it to my laptop and radio, and it successfully connected to a PACTOR station. The operators of two PACTOR stations modified their configurations to recognize my station. Then I was able to send and retrieve national traffic system (NTS) messages.

I now routinely log in to retrieve NTS messages from The 3rd Region Hub for The Western Pennsylvania Section, on every even numbered day, sharing the responsibility with another amateur radio operator who checks in on odd numbered days. After retrieving messages, I relay them via The Western Pennsylvania Phone Traffic Net, or deliver them via phone, email or US Mail. I also originate my own messages to send via the NTS.

Contact me if you wish to originate an NTS message.

More Antenna Woes

BillLeave a comment

Today, one leg of my G5RV antenna snapped off due to the extreme cold and windy conditions. The temperature now is 9 F with a windchill of -8 F. My HF system is now out of commission until I can install a new antenna, or install the new dedicated 80-meter antenna. Sunday it will warm to the low 40s so that is the earliest I can make the attempt. Temperatures will be above freezing from Sunday until at least next Tuesday.



Right now it looks as though my NTS production for January will be a total of 41 handled messages. That is a personal monthly record.



Update: G5RV antenna was replaced.

Antenna Wear and Tear

BillLeave a comment

Stormstown is nestled in Halfmoon Valley. The valley is often windy, with the flow mainly from the southwest. The winds have been taking a toll on my outdoor equipment, mainly the flags and flagpole, and my G5RV HF amateur radio antenna.

Most of the damage has been minor. In the past six months, I have had to replace the dipole wires, resolder the ladder line connectors at the feed point, replace a section of coax due to a broken connection at the feed point, and replace two clamps and three sections for the collapsible mast.

During my latest repair, to replace the coax, I secured the ladder line with cable ties. That may reduce some of the wear and tear on the cables and connections.

I am a frequent check-in on the 3rd Region Net at 2100 UTC (3.918 MHz, LSB), and The Western PA Phone Traffic Net at 2200 UTC (3.983 MHz, LSB). My callsign is WX2DX.

nts_clInformation on the National Traffic System

If you’d like to send a radiogram, send me a comment.

Amateur Radio Traffic Net

BillLeave a comment

Last Week, I became a regular check-in to The Western Pennsylvania Phone Traffic Net. I started to look for a net after the landfall of Hurricane Harvey. The net meets every evening at 6 PM on 80-meters, and is part of The National Traffic System (NTS).

So far, I’ve initiated 4 radiograms. I hope to continue handling NTS messages on a regular basis.
